Intel S4500 Entry - Solid state drive - encrypted - 480 GB - hot-swap - 2.5" - SATA 6Gb / s - 256-bit AES - for ThinkAgile VX 2U Certified Node; ThinkSystem SR530; SR550; SR570; SR590; SR850; SR860
Intel S4500 Entry - Solid state drive - encrypted - 480 GB - hot-swap - 2.5" - SATA 6Gb / s - 256-bit AES - for ThinkAgile VX 2U Certified Node; ThinkSystem SR530; SR550; SR570; SR590; SR850; SR860
Manufacturer
•LENOVO
Reference
•7SD7A05741
Article
•1519166
Intrastat
•84717050
Shipping weight
•0.19 kg
Device Type
Solid state drive - hot-swap
Capacity
480 GB
Hardware Encryption
Yes
Encryption Algorithm
256-bit AES
NAND Flash Memory Type
3D triple-level cell (TLC)
Form Factor
2.5"
Interface
SATA 6Gb/s
Features
Enhanced Power Loss Data Protection, Thermal throttling, End-to-end data path protection, End-to-end data protection, 3D NAND Technology, Standard Endurance Technology (SET), S.M.A.R.T.
Width
70 mm
Depth
100 mm
Height
7 mm
Weight
63 g
Drive Writes Per Day (DWPD)
1.03
SSD Endurance
900 TB
Drive Transfer Rate
600 MBps (external)
Internal Data Rate
500 MBps (read) / 330 MBps (write)
4KB Random Read
72000 IOPS
4KB Random Write
20000 IOPS
Average Latency
36 µs
MTBF
2,000,000 hours
Non-Recoverable Errors
1 per 10^17
Interfaces
1 x SATA 6 Gb/s
Compatible Bay
2.5"
Power Consumption
3.6 Watt (typical)
Compliant Standards
C-Tick, KCC, BSMI CNS 13438, EN 60950-1 Second Edition, RoHS 2011/65/EU, LVD 2006/95/EC, EN55022:2006, WEEE 2002/96/EC, EN55024:1998, CAN/CSA-CEI/IEC CISPR 22:02, FCC CFR47 Part 15 B Class B, AS/NZS 3584
Service & Support
Limited warranty - replacement - 1 year - carry-in
Min Operating Temperature
0 °C
Max Operating Temperature
70 °C
Humidity Range Operating
5 - 95% (non-condensing)
Shock Tolerance (operating)
1000 g @ 0.5 ms
Vibration Tolerance (operating)
2.17 g @ 5-700 Hz
Vibration Tolerance (non-operating)
3.13 g @ 5-800 Hz
Designed For
Lenovo ThinkAgile VX 2U Certified Node (2.5") ¦ Lenovo ThinkSystem SD530 (2.5") ¦ Lenovo ThinkSystem SN550 (2.5") ¦ Lenovo ThinkSystem SN850 (2.5") ¦ Lenovo ThinkSystem SR530 (2.5") ¦ Lenovo ThinkSystem SR550 (2.5") ¦ Lenovo ThinkSystem SR570 (2.5") ¦ Lenovo ThinkSystem SR590 (2.5") ¦ Lenovo ThinkSystem SR630 (2.5") ¦ Lenovo ThinkSystem SR650 (2.5") ¦ Lenovo ThinkSystem SR850 (2.5") ¦ Lenovo ThinkSystem SR860 (2.5") ¦ Lenovo ThinkSystem ST550 (2.5")
