Lenovo ThinkSystem 5100 Enterprise Entry - Solid state drive - encrypted - 480 GB - hot-swap - 2.5" - SATA 6Gb / s - 256-bit AES - for ThinkSystem SD530; SN850; SR530; SR550; SR570; SR590; SR630; SR650; SR850; SR860; ST550
Lenovo ThinkSystem 5100 Enterprise Entry - Solid state drive - encrypted - 480 GB - hot-swap - 2.5" - SATA 6Gb / s - 256-bit AES - for ThinkSystem SD530; SN850; SR530; SR550; SR570; SR590; SR630; SR650; SR850; SR860; ST550
Manufacturer
•LENOVO
Reference
•4XB7A08502
Article
•1541217
Intrastat
•84717050
Shipping weight
•0.19 kg
Device Type
Solid state drive - hot-swap
Capacity
480 GB
Hardware Encryption
Yes
Encryption Algorithm
256-bit AES
NAND Flash Memory Type
3D triple-level cell (TLC)
Form Factor
2.5"
Interface
SATA 6Gb/s
Features
3D NAND Technology, S.M.A.R.T.
Width
70 mm
Depth
100 mm
Height
7 mm
Weight
70 g
Drive Writes Per Day (DWPD)
0.5
SSD Endurance
450 TB
Drive Transfer Rate
600 MBps (external)
Internal Data Rate
540 MBps (read) / 380 MBps (write)
4KB Random Read
93000 IOPS
4KB Random Write
31000 IOPS
Average Latency
500 µs
MTBF
2,000,000 hours
Non-Recoverable Errors
1 per 10^17
Interfaces
1 x SATA 6 Gb/s
Compatible Bay
2.5"
Power Consumption
4.5 Watt (typical)
Compliant Standards
TUV, RRL, IEC 60950, RoHS, EN 60950-1, UL 60950-1 Second Edition, KCC, BSMI CNS 13438, FCC CFR47 Part 15 B, RCM, WEEE 2002/96/EC, EN 55032 Class B, KCC KN32 Class B, AS/NZS CISPR32 Class B, KCC KN35 Class B, Micron Green Standard, VCCI 2015.04 Class B, ICES-003:2016
Service & Support
Limited warranty - replacement - 1 year - carry-in
Min Operating Temperature
0 °C
Max Operating Temperature
70 °C
Humidity Range Operating
5 - 95% (non-condensing)
Shock Tolerance (non-operating)
1500 g @ 0.5 ms
Vibration Tolerance (non-operating)
3.13 g @ 5-800 Hz
Designed For
Lenovo ThinkSystem SD530 (2.5") ¦ Lenovo ThinkSystem SN550 (2.5") ¦ Lenovo ThinkSystem SN850 (2.5") ¦ Lenovo ThinkSystem SR530 (2.5") ¦ Lenovo ThinkSystem SR550 (2.5") ¦ Lenovo ThinkSystem SR570 (2.5") ¦ Lenovo ThinkSystem SR590 (2.5") ¦ Lenovo ThinkSystem SR630 (2.5") ¦ Lenovo ThinkSystem SR650 (2.5") ¦ Lenovo ThinkSystem SR850 (2.5") ¦ Lenovo ThinkSystem SR860 (2.5") ¦ Lenovo ThinkSystem ST550 (2.5")
