Network surveillance camera

Yes: 10-band graphic equaliser, speaker pairing, microphone pairing, two-way audio capability

AAC-LC, G.711, PCM, G.726, ADPCM, OPUS, LPCM

Bullet

Wired

8 cm

18 cm

6.2 cm

529 g

Argentina, Australia, Brazil, China, Europe, Japan, United Kingdom, United States

Colour - Day&Night - fixed

H.264, H.265, MJPEG, MPEG-H Part 2, MPEG-4 Part 10, AVC, HEVC, AV1

3840 x 2160

Yes

4K

1/66500 sec - 2 sec

0.05 lux - colour - F1.6 - 2.9 - 50 IRE - Forensic WDR and Lightfinder ¦ 0.01 lux - B&W - F1.6 - 2.9 - 50 IRE - Forensic WDR and Lightfinder

3840 x 2160, WDR on, 50/60 Hz @ 25/30 fps ¦ 2560 x 1600, WDR on, 50/60 Hz @ 25/30 fps ¦ 2592 x 1944, WDR on, 50/60 Hz @ 25/30 fps ¦ 160 x 90, WDR on, 50/60 Hz @ 25/30 fps ¦ 160 x 100, WDR on, 50/60 Hz @ 25/30 fps ¦ 160 x 120, WRD on, 50/60 Hz @ 25/30 fps ¦ 3840 x 2160, WDR off, 50/60 Hz @ 50/60 fps ¦ 2560 x 1600, WDR off, 50/60 Hz @ 50/60 fps ¦ 2592 x 1944, WDR off, 50/60 Hz @ 50/60 fps ¦ 160 x 90, WDR off, 50/60 Hz @ 50/60 fps ¦ 160 x 100, WDR off, 50/60 Hz @ 50/60 fps ¦ 160 x 120, WRD off, 50/60 Hz

IR Corrected lens, automatic IR-cut filter, hybrid IR filter, deep learning processing unit (DLPU), 20 video streams, Zipstream technology, controllable frame rate, controllable bandwidth, Variable Bitrate (VBR), Adaptive Bitrate (ABR), low latency mode, Multi-Bitrate (MBR), video streaming indicator, >55 dB SNR, Forensic WDR, up to 7 individually cropped out view areas, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), saturation control, contrast control, brightness control, sharpness control, white balance, 180° image rotation, 270° image rotation, 90° image rotation, barrel distortion correction, compression, day/night threshold, Defog, electronic image stabilisation, exposure control, local contrast control, programmable exposure zones, tone mapping, dynamic text overlay, polygon privacy mask, mosaic privacy mask, target aperture, Lightfinder 2.0 technology, digital PTZ function, PELCO D protocol support, VISCAIP protocol support, auto gain control, ONVIF (Profile G) support, ONVIF (Pro

8 MP PS RGB CMOS 1/1.2"

Vari-focal

2.3 x

5.9 mm - 13.3 mm

F/1.6-2.9 (P-Iris)

0.5 m

49 - 108

27 - 58

Ethernet 10Base-T/100Base-TX/1000Base-T

IPv4, IPv6, USGv6, ICMPv4, ICMPv6, HTTP, HTTPS, HTTP/2, TLS, QOS, FTP, SFTP, CIFS, SMTP, MDNS, Bonjour, UPnP, SNMP 1, DNS, DNSv6, DDNS, NTP, NTS, RTSP, RTP, SRTP, RTSPS, TCP, UDP, IGMP, RTCP, ICMP, DHCPv4, ARP, SSH, LLDP, CDP, MQTT, DHCPv6, IGMPv2, IGMPv3, SNMP 2c, SNMP 3, SMB

Audio line-in/microphone ¦ LAN/power - RJ-45 ¦ Serial RS-485/RS-422 - terminal block ¦ HDMI - Type D ¦ AHI

microSD Card, microSDHC Card, microSDXC Card

EAP-TLS, PEAP, TLS 1.2, TLS 1.3

Stand, owner authentication key, terminal block connectors, allen key

Yes

CSA, UL/cUL, VCCI, RCM, CISPR 35, CISPR 32 Class A, EN 55035, EN 55032 Class A, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, IEC 62236-4, AS/NZS, ICES Class A, NMB-3 Class A, VCCI Class A, FCC Part 15 B Class A, CAN/CSA C22.2 No. 62368-1 Third Edition, IEC/EN/UL 62368-1 Third Edition, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, NIST SP500-267, EN 303 645, FIPS 140, IEEE 802.1ar, IEEE 802.1x, X.509, IEEE 802.3af, IEEE 802.3at, 2011/65/EU, EN/IEC 63000:2018, 2015/863, REACH, ECA, JEDEC, JS709

NCS S 9000-N

DC 10 - 28 V / PoE Class 3

7 Watt

AXIS Object Analytics, AXIS Scene Metadata, AXIS Image Health Analytics, AXIS Live Privacy Shield, AXIS Speed Monitor, AXIS Video Motion Detection

Limited warranty - 5 years

-10 °C

60 °C

10 - 85% RH (non-condensing)
