ASRock G41C-GS - 2.0 - motherboard - micro ATX - LGA775 Socket - G41 Chipset - Gigabit LAN - onboard graphics - HD Audio (6-channel)
ASRock G41C-GS - 2.0 - motherboard - micro ATX - LGA775 Socket - G41 Chipset - Gigabit LAN - onboard graphics - HD Audio (6-channel)
Ražotājs
•HONEYWELL
Ražotāja kods
•PS-PLUG-U
Artikuls
•1858492
Intrastat
•84717020
Product Type
Motherboard - micro ATX
Chipset Type
Intel G41 Express / Intel ICH7
Max Bus Speed
1333 MHz
Processor Socket
LGA775 Socket
Max Processors Qty
1
Compatible Processors
Pentium, Celeron, Pentium 4, Celeron D, Pentium D, Core 2 Duo, Core 2 Extreme, Core 2 Quad, Celeron 400 sequence
Max Size
8 GB
Technology
DDR2, DDR3
Bus Clock
1066 MHz, 800 MHz, 667 MHz, 533 MHz, 1333 MHz (O.C.)
Speed
PC3-10600, PC3-8500, PC3-6400, PC2-6400, PC2-5300, PC2-4300
Supported RAM Integrity Check
Non-ECC
Registered or Buffered
Unbuffered
Features
Dual channel memory architecture
Graphics Controller
Intel GMA X4500
Memory Allocation Technology
Dynamic Video Memory Technology 5.0
Max Allocated RAM Size
1759 MB
Type
HD Audio (6-channel)
Audio Codec
Realtek ALC662
Compliant Standards
High Definition Audio
Network Controller
Realtek RTL8111GR
Network Interfaces
Gigabit Ethernet
Expansion Slots
1 x CPU
2 x DIMM 240-pin (DDR2)
2 x DIMM 240-pin (DDR3)
1 x PCIe x16
1 x PCIe x1
2 x PCI
Storage Interfaces
Intel ICH7: SATA-300 -connectors: 4 x 7pin Serial ATA - 4 devices
Intel ICH7: ATA-100 -connectors: 1 x 40pin IDC - 2 devices
Interfaces
1 x PS/2 mouse
1 x PS/2 keyboard
1 x serial
1 x VGA
4 x USB 2.0
1 x LAN (Gigabit Ethernet)
1 x audio line-in - mini-jack
1 x audio line-out - mini-jack
1 x microphone - mini-jack
Internal Interfaces
1 x floppy
1 x audio
2 x USB 2.0 - header
Power Connectors
4-pin ATX12V connector, 24-pin main power connector
BIOS Type
AMI
BIOS Features
JumperFree, Hyper-Threading Technology, ACPI 1.1 support, Untied Overclocking Technology
Manual Settings
Processor core voltage, chipset voltage
Hardware Monitoring
CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, power supply fan tachometer
Sleep / Wake Up
Wake on LAN (WOL)
Hardware Features
Chassis intrusion detection, ASRock Hybrid Booster, ASRock U-COP, Intelligent Energy Saver, ASRock Instant Boot, ASRock OC Tuner, ASRock OC DNA, ASRock Instant Flash, ASRock CPU Frequency Stepless Control, ASRock Boot Failure Guard (B.F.G.), ASRock XFast LAN, ASRock XFast RAM, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), LAN Cable Detection, ASRock Full Spike Protection
Included Accessories
I/O back plate
Cables Included
2 x Serial ATA cable
Software Included
Drivers & Utilities, Antivirus (Trial version), Start8 (30 days trial), Google Chrome Browser, Google ChromeToolbar
Compliant Standards
Plug and Play, FCC, EuP Ready, ErP Ready
