Teltonika TSW100 - Switch - unmanaged - 5 x 10 / 100 / 1000 (4 PoE) - DIN rail mountable, surface-mountable, wall-mountable - PoE (120 W)
Teltonika TSW100 - Switch - unmanaged - 5 x 10 / 100 / 1000 (4 PoE) - DIN rail mountable, surface-mountable, wall-mountable - PoE (120 W)
Ražotājs
•TELTONIKA
Ražotāja kods
•TSW100010000
Artikuls
•4506341
Intrastat
•85176200
Pakas svars
•0.35 kg
Kopā pieejams (gab.)
•10
Tuvākā piegāde
•16.03.2026
Device Type
Switch - 5 ports - unmanaged
Enclosure Type
DIN rail mountable, surface-mountable, wall-mountable
Subtype
Gigabit Ethernet
Ports
5 x 10/100/1000 (4 PoE)
Power Over Ethernet (PoE)
PoE
PoE Budget
120 W
Performance
Non-blocking bandwidth: 10 Gbps
Capacity
Packet buffer size: 128 KB
MAC Address Table Size
2K entries
Jumbo Frame Support
9216 bytes
Features
Auto-uplink (auto MDI/MDI-X), PROFINET, ground points, aluminium housing
Compliant Standards
IEEE 802.3ab, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at
Status Indicators
Power, status
Interfaces
4 x 1000Base-T RJ-45 PoE - 30 W ¦ 1 x 1000Base-T RJ-45
Power Device
External power adapter
Power Provided
62 Watt - DC 48 V - 1.3 A
Voltage Required
AC 100-240 V (50/60 Hz)
Electric Current Required
1.5 A
Compliant Standards
IP30, UKCA, EAC, UCRF, CITC, ANRT, FCC, IC, NOM, ANATEL, CB, E Mark, EN 55032:2015, EN 55035:2017, EN 301 489-1 V2.2.3, EN 61000-4-2:2009, EN IEC 61000-4-3:2006 + A1:2008 + A2:2010, EN 61000-4-4:2012, EN 61000-4-5:2014, EN 61000-4-6:2014, EN 61000-4-11:2004, IEC 62368-1:2018, EN IEC 62368-1:2020+A11:2020
Localisation
Europe
Width
11.5 cm
Depth
10.12 cm
Height
3.22 cm
Weight
350 g
Shipping Width
17.5 cm
Shipping Depth
15 cm
Shipping Height
3.5 cm
Min Operating Temperature
-40 °C
Max Operating Temperature
75 °C
Humidity Range Operating
5 - 95% (non-condensing)
